Einsy Rambo 3D Printer Motherboard Kit - Complete Upgrade Board for Prusa i3 MK3, MK2 & Other 3D Printers | Perfect for DIY 3D Printing Projects & Repairs

Product Description

This is Einsy Rambo 1.2. The Einsy Rambo board is an all in one 3D printer motherboard. It is a compact design with the Arduino Compatible MEGA and Trinamic TMC2130 stepper drivers all on one integrated PCB. A great alternative board if you need just the basics! Einsy Rambo is designed to work with the current RAMPS generation firmwares with minimal modifications to add firmware motor current control and the microstep setting. Item Specifics 1 - Pre-Assembled Einsy Rambo PCB 2 - Crimped/housed thermistor wire harness, 914.4mm (36") *thermistor not included* 1- Black 2-pin pluggable terminal block 2 - Gold connectors & matching 1x2 positive latch housing 2 - Gold connectors & matching 1x3 positive latch housing 5 - Gold connectors & matching 1x4 positive latch housing (for motor cables) 1 - USB Cable - 1.828m (6ft) 3 - Mechanical endstop switches 1 - Mechanical endstop harness, 609.6mm (24") Recommended Power supply: 12V-24V DC, 16A+ 4 PWM Mosfet outputs 3 thermistor inputs + ZProbe thermistor 2 fuse protected power rails A preconfigured Marlin Firmware is preloaded onto the board
